Pneumatic air metal fitting is an important part for connecting various pneumatic components and transmitting compressed air in pneumatic system.
MODEL | φD | R | L1 | L2 | L3 | φD1 | |
NC04-M5 | 4 | M5 | 3.5 | 22.5 | 38 | 11.5 | 10 |
NC04-M5 | 4 | M6 | 4 | 23 | 38 | 11.5 | 10 |
NC04-01 | 4 | R1/8 | 7.5 | 25 | 38 | 11.5 | 10 |
NC04-02 | 4 | R1/4 | 9.5 | 28 | 38 | 11.5 | 14 |
NC04-03 | 4 | R3/8 | 10.5 | 29.5 | 38 | 11.5 | 17 |
NC06-M5 | 6 | M5 | 3.5 | 23.2 | 39 | 13.5 | 12 |
NC06-M6 | 6 | M6 | 4 | 23.7 | 39 | 13.5 | 12 |
NC06-01 | 6 | R1/8 | 7.5 | 25.7 | 39 | 13.5 | 12 |
NC06-02 | 6 | R1/4 | 9.5 | 28.2 | 39 | 13.5 | 14 |
NC06-03 | 6 | R3/8 | 10.5 | 29.7 | 39 | 13.5 | 17 |
NC06-04 | 6 | R1/2 | 13.5 | 33.2 | 39 | 13.5 | 21 |
NC08-01 | 8 | R1/8 | 7.5 | 29.5 | 45 | 15 | 14 |
NC08-02 | 8 | R1/4 | 9.5 | 31.5 | 45 | 15 | 14 |
NC08-03 | 8 | R3/8 | 10.5 | 33 | 45 | 15 | 17 |
NC08-04 | 8 | R1/2 | 13.5 | 36.5 | 45 | 15 | 21 |
NC10-01 | 10 | R1/8 | 7.5 | 35 | 57 | 19 | 17 |
NC10-02 | 10 | R1/4 | 9.5 | 37 | 57 | 19 | 17 |
NC10-03 | 10 | R3/8 | 10.5 | 38 | 57 | 19 | 17 |
NC10-04 | 10 | R1/2 | 13.5 | 41.8 | 57 | 19 | 21 |
NC12-01 | 12 | R1/8 | 7.5 | 36 | 59 | 21.5 | 21 |
NC12-02 | 12 | R1/4 | 9.5 | 38.5 | 59 | 21.5 | 21 |
NC12-03 | 12 | R3/8 | 10.5 | 39.5 | 59 | 21.5 | 21 |
NC12-04 | 12 | R1/2 | 13.5 | 42.5 | 59 | 21.5 | 21 |
NC14-03 | 14 | R3/8 | 10.5 | 41 | 54 | 23.5 | 22 |
NC14-04 | 14 | R1/2 | 13.5 | 44 | 54 | 23.5 | 22 |
NC15-03 | 15 | R3/8 | 10.5 | 44 | 66 | 26.5 | 24 |
NC15-04 | 15 | R1/2 | 13.5 | 47 | 66 | 26.5 | 24 |
NC16-03 | 16 | R3/8 | 10.5 | 44 | 66 | 26.5 | 24 |
NC16-04 | 16 | R1/2 | 13.5 | 47 | 66 | 26.5 | 24 |
NC16-06 | 16 | R3/4 | 15 | 49 | 66 | 26.5 | 27 |
Pneumatic air metal fitting firmly connect the air source (such as air compressor), pneumatic actuator components (such as cylinders, air motors, etc.), and pneumatic control components (such as solenoid valves, pneumatic valves, etc.) together to ensure the integrity of the entire pneumatic system. And provide a sealed and unobstructed transmission channel for compressed air to ensure that air can be accurately transported to the required part to drive the normal operation of pneumatic equipment.
1- Reusable: Under normal use and maintenance conditions, Pneumatic air metal fitting multiple connection and disconnection operations can be performed without affecting performance.
2- Strong interchangeability: Pneumatic air metal fitting of the same specification produced by different manufacturers generally have good interchangeability, which is convenient for users to choose and replace.
Industrial manufacturing field
Automated production lines: such as automobile manufacturing, electronic equipment assembly and other production lines, used to connect various pneumatic executive components (such as cylinders to push the mechanical arm to grasp, carry and other actions) and control components (such as solenoid valves to control the action sequence of the cylinder, etc.) to ensure efficient and stable operation of the production line.
Machine tool processing: provide compressed air transmission channel for the pneumatic fixture and pneumatic tool change device of the machine tool, realize the clamping of the workpiece, the quick replacement of the tool and other operations, improve the processing efficiency and accuracy.
